5500 Pro
Regenerate with your own heat
Operating in both capacitive and resistive modes, the Diacare 5500 Pro is versatile for treating both acute and chronic disorders of the osteoarticular and muscular systems. This tecar therapy machine produces high-frequency currents that utilize your body’s internal energies, stimulating natural self-regeneration processes in tissues and muscles.
5500 Pro Features
Greater Variety of Frequencies
400, 448, 470, 700, 1000 KHz
Expanded treatment options with six unique frequencies.
Suggested Protocols
Pre-installed Protocols
Built-in treatment suggestions for optimal therapy settings.
Integrated Photos
Visual treatment Guides
Photos on the device for accurate treatment positioning.
Self Calibration
Real-Time Adjustment
Measures tissue impedance to maintain consistent energy levels.
Truly Portable
Portable Therapy Machine
Compact and lightweight design for easy transport.
Capacitive & Resistive Modality
Dual-Mode Operation
Versatile treatment options with capacitive and resistive modes.
Hand Pieces
Various Shapes and Sizes
Different hand pieces for tailored treatments.
Self-Adhesive Electrodes
Treatment in Motion
Self-adhesive electrodes for performing treatments while in motion.
Technical Specifications
- Display: Size 4.3” color display
- Power: 200W ±10%
- Outputs: 2
- Emission Frequency: 400kHz, 448 kHz, 470kHz, 700kHz, 1000kHz ± 10%
- Treatment modality: Capacitive and resistive
- Capacitive electrodes: 3 size (Ø mm 30, 50, 70)
- Resistive electrodes: 3 size (Ø (mm 30, 50, 70)
- Mains supply: 100-240V AC, 50-60Hz, 1.8A
- Size:mm 120x220x60
- Weight: 2.5 lbs
Equipment
- 1 DIACARE 5500 Pro tecar therapy unit
- 1 Return electrode (plate)
- 1 Monopolar resistive handpiece with 3 heads (Ø mm 30, 50, 70)
- 1 Monopolar capacitive handpiece with 3 heads Ø (mm 30, 50, 70)
- 1 Bipolar handpiece Ø (50 mm) (Optional)
- 1 Kit for automatic treatment (Optional)
- 250ml of cream
- 1 Power supply unit
- 1 Operating manual
Special Features
- RESISTIVE
- CAPACITIVE
- BIPOLAR
- PRESET PROGRAMS
- FREE HANDS
- MULTIFREQUENCY
- PULSED TREATMENTS
- AUTOMATIC FREQUENCY SCANNING
- TRANSDERMAL DELIVERY
- ATHERMY TREATMENTS
- TOUCH SCREEN NAVIGATION
- COLOR DISPLAY
Areas of Full Range Protocol
Diacare 5500 Pro provides tailored protocols to address a wide range of specific sports injuries.
- XXX SUGGESTED PROTOCOLS
- PULSED EMISSION PROGRAMS
- AUTO: These programs should be used for treatments in HANDS-FREE MODE
- SPECIAL PROGRAMS
- SCAN: Uniformly conveys energy for a comprehensive overall treatment
- ATHERMY: Designed to biostimulate tissues without generating heat, promoting healing and regeneration in a gentle, non-invasive manner.
- TRANSDERMAL DELIVERY: Enhances the effectiveness of topical treatments by facilitating the absorption of active ingredients and promoting deeper penetration into the tissues.
